Pumping Mechanism

Curvilinear peristaltic

IV Sets

Compatible with IV sets of any standard (Ф3.8mm±0.2mm, δ<0.5mm)

Flow Rate

1-1100 ml/h in 1 ml/h increments

Purge, Bolus

Purge when pump stops, bolus when pump starts

Rate at 700 ml/h

Accuracy

Universal IV set: ±5%

Volume

1-9999 ml in 1ml increments

Infusion Modes

ml/h, drop/min

KVO Rate

4 ml/h

Alarms

Occlusion, air-in-line, door open, end program, low battery,

unattended pump after startup, system malfunction

Additional Features

Real-time shift totals, automatic power switching,

mute button, purge, bolus

Occlusion Sensitivity

0.1-0.14 Mpa, adjustable

Air-in-Line Detection

Ultrasonic detector

Infusion Management System

Optional

Drop Sensor

Optional

Vehicle Power

Available

Power Supply

AC: 230 V, 50 Hz

Battery: 9.6±1.6 V, rechargeable

Vehicle power: 12±1.2 V

Battery Life

3 hours at 30 ml/h

Working Temperature

10-30℃

Relative Humidity

30-75%

Atmospheric Pressure

860-1060 hpa

Size

130*145*228 mm

Weight

2.5 kgs

Safety Classification

Class Ⅰ, type CF
