The product has more excellent optical performance and can be connected with international standard interface.
Features
◆
Converging stereoscope microscope provides the clear images.
◆
Schott optic lenses from Germany are used to reduce optical distortion and increase clarity and depth of focus.
◆
Optical effect is maintained by multi-layer coating treatment of moisture-proof, mildew-proof and anti-reflected on lenses.
◆
Eyepieces can be switched with switch zoom in objective lens can obtain magnifications in 10×, 16× and 25.6×) to satisfy the needs in whole and fine inspection
◆
All interfaces can connect with accessories comply with international standards.
Microscope
Microscope Type
Galileo magnification changer with converging
Magnification Change
Switch zoom
Eyepieces
10x, 16x
Magnifications
(Field of View)
10x eyepiece: 10x(φ18 mm), 16x( φ14.5 mm )
16x eyepiece: 16x( φ11.25 mm ), 25.6x( φ9 mm )
Pupilary Adjustment
10x eyepiece: 55 mm～82 mm
16x eyepiece: 51 mm～78 mm
Diopter Adjustment
10x eyepiece: ±8D
16x eyepiece: ±10D
Slit Illumination
Slit Width
continuously variable from 0 ～9 mm adjustable(at 9 mm, slit becomes a circle )
Slit Height
continuously variable from 1 mm～8 mm
Slit Angle
0°～180° (continuously adjustable both vertical and horizontal)
