Type of System

•Automated discrete, STAT priority

Throughput

•Constant 1200 test/h(biochemistry 600 test/h, standard configuration ISE 600 test/h

Measuring principle

•Endpoint, rate, fixed-time, colorimetry,turbidimetry,ion-selective electrode technology

Calibration method

•1-point linear method,2-point linear method,multipint linear method,non-linear method

Sample handling

•115 sample positions,continuous loading,support polytype primary tube& microcontainer cup

Reagent handling

•2 trays,90 positions,refrigerated with independent power switch, continuous loading

Sample volume

•2 μL-35μL, 0.1μL stepping

Reagent volume

•20 μL-350μL,1μL stepping

Reaction volume

•Minimal reaction volume as low as 150 μL

Reaction cuvette

•120,optical diameter is 6 mm

Reaction temperature

•37℃±0.1℃

Light source

•Halogen lamp, lifespan up to 2500 hours

Wavelength

•340nm,380nm,405nm,480nm,505nm,546nm,570nm,600nm,630nm,660nm,

700nm,720nm,750nm,780nm,800nm

Water consumption

•Deionized water 15 liter/hour

Dimensions

•1220mm*800mm*1150mm

Weight

•230Kg
