Principle of Luminescence
•Non-enzyme involved flash chemiluminescence, long stability of reagents
•ABEI label, stable in acid and alkaline solution

Main Features
•Throughput: up to 180 tests/hour
•24 hours ready-to-use
•Time to first result:17 minutes

Modes of Operation
•Random, Batch and STAT

Sample Loading
•Up to 144 primary tubes
•Continuous loading, STAT available
•Barcode reader recognition or analyzer auto numbered
•LIS connection, auto read sample info
•Refrigerated sample area with independent power supply

Reagent Loading
•25 reagents on board
•Continuous loading
•RFID reading all info of reagents
•Refrigerated reagent area

Reagent Features
•Integrated kit, ready-to-use, no pretreatment required
•Integrated kit including calibrators
•Using superparamagnetic micrbeads
•RFID tag storing all info of reagent
•RFID tag with built-in master curve
•2-point calibration to adjust master curve
•Calibration stability: Max 4 weeks

Other Features
•Clot detection
•Liquid level detection for reagent
•Optional ratio for sample dilution
•Auto dilution for high concentration sample
•Constant 37℃ incubation
•15-30℃ Operating Temperature

Operation System
•Windows XP
•HP compatible (Dual-core CPU)
•Color touch screen

Interconnection
•Connection to LIS via COM or network card
•Direct operation on LIS system to test

Dimensions Weight
•144×76×152cm, 228kg
