Principle of Luminescence
•Non-enzyme involved flash chemiluminescence, long stability of reagents
•ABEI label, stable in acid and alkaline solution

Main Features
•Throughput: up to 120 tests/hour
•24 hours ready to use
•Time to first result:17 minutes

Modes of Operation
•Random, Batch and STAT

Sample Loading
• Up to 144 primary tubes
• Continuous loading, STAT available
• Analyzer auto numbered
• LIS connection

Reagent Loading
•15 reagents on board
•Continuous loading
•RFID read all info of reagent
•Refrigerated reagent area

Reagent Features
•Integrated kit, ready-to-use, no pretreatment required
•Integrated kit including calibrators
•Use superparamagnetic microbeads
•RFID tag storing all info of reagent
•RFID tag with built-in master curve
•2-point calibration to adjust master curve
•Calibration stability: max 4 weeks

Other Features
•Clot detection
•Liquid level detection for reagent
•Optional ratio for sample dilution
•Auto dilution for high concentration sample
•Constant 37℃ incubation
•15-30℃ Operating temperature

Interconnection
•Connection to LIS via COM or network
•Direct operation on LIS system to test

Dimensions Weight
•135×64×87cm, 148kg
