Technical Specification

Scanning: Convex, linear multi-frequency with wide band

Display Mode: B, B + B, B + M, M

Gray Scale: 256 levels

Monitor Size: 10.4 "color TFT LCD

Cine-memory: 256 frames (vet)

32 permanent storage Image

Image Conversion: U / D, L / R and B / W

Image magnification: × 1.0 × 1.2 × 1.5 × 2.0 times

Image Procession: DFS, DRF, RDA, VGA / DSC and Image pre & post

Measurement: Distance, Circumference / Area, Heart Rate, EF rate for heart and GS, CRL, BPD, HC, FL, AC for OB / GY measurement, and Gestational Age, Fetal weight, EDD

Multi-step Zoom (1: 2) in Both real-time and frozen modes

Focusing selectable

Depth adjustable in read-time of B and B + B-mode

8 different coded-color on a external color monitor 15 different kinds of body marks

Characteristics showing in real-time clock, ID, Sex, Age, Focusing info and Hospital name

standard configuration

(for vet use) main unit with a 6.5MHz linear rectal probe

option probe

((for vet use) ①R40 / 3.5MHz convex probe ②R20 / 5.0MHz micro-convex probe

③L40 / 7.5MHz linear probe ④L40 / 7.5MHz endorectal probe
