Specifications∶ ·Assay methods: End Point, Kinetic, Fix time etc. ·Principle: Photoelectric Colorimetry ·Light Source: Halogen lamp 12V/20W ·Photometry range: 0~3Abs ·Resolution: 0.0001Abs ·Wavelength: 10 wavelengths optional (340nm~800nm) ·Throughput: 300tests/hour ·Reagent tray: 59 reagent positions, 1 detergent position ·Sample tray: 45sample positions, including detergent, standard, QC, STAT positions ·Reaction tray: 120 reaction positions ·Sample volume: 2~100ul, with 0.1ul increment ·Reagent volume: R1:10~500ul, R2: 10~500ul, with 0.5ul increment ·Minimum reaction volume: 150uL ·Maximum reaction time: 10 minutes ·Water Consumption: 6L/hour under working status ·Clean unit: 8-step auto-washing system with detergent and 37℃ water ·Calibration: Calibration reset, select best test point by reaction curve, no need second calibration Line/non-line;multi-standards assaycalibration ·Control rules: Westgard multi-rule, Cumulative sum check, Twin plot 3 level controls for each ifem,analyxing and printing QC analysis diagram ·Temperature control: incubator 37±0.1℃ ·Power supply: AC110/230(1±10%)V, 50/60Hz, 500VA ·Ambient: Operating temperature: 10~30℃ Relative humidity: ≤85%
Features∶ ·24 hour non-stop water cycle cooling system to ensure reagent at 2-8℃ ·Dual-unattached durable ceramic syringes to ensure accuracy & precision ·Collision protection in both vertical and horizontal directions, stop & alarm automatically once touching barrier, not affect former tests ·Automatic eligible cuvettes detection & selection ·Select best test point by reaction curve, create new factor automatically ·High accurate optical system ·Support LIS interface
Specifications∶ ·Assay methods: End Point, Kinetic, Fix time etc. ·Principle: Photoelectric Colorimetry ·Light Source: Halogen lamp 12V/20W ·Photometry range: 0~3Abs ·Resolution: 0.0001Abs ·Wavelength: 10 wavelengths optional (340nm~800nm) ·Throughput: 300tests/hour ·Reagent tray: 59 reagent positions, 1 detergent position ·Sample tray: 45sample positions, including detergent, standard, QC, STAT positions ·Reaction tray: 120 reaction positions ·Sample volume: 2~100ul, with 0.1ul increment ·Reagent volume: R1:10~500ul, R2: 10~500ul, with 0.5ul increment ·Minimum reaction volume: 150uL ·Maximum reaction time: 10 minutes ·Water Consumption: 6L/hour under working status ·Clean unit: 8-step auto-washing system with detergent and 37℃ water ·Calibration: Calibration reset, select best test point by reaction curve, no need second calibration Line/non-line;multi-standards assaycalibration ·Control rules: Westgard multi-rule, Cumulative sum check, Twin plot 3 level controls for each ifem,analyxing and printing QC analysis diagram ·Temperature control: incubator 37±0.1℃ ·Power supply: AC110/230(1±10%)V, 50/60Hz, 500VA ·Ambient: Operating temperature: 10~30℃ Relative humidity: ≤85%
Features∶ ·24 hour non-stop water cycle cooling system to ensure reagent at 2-8℃ ·Dual-unattached durable ceramic syringes to ensure accuracy & precision ·Collision protection in both vertical and horizontal directions, stop & alarm automatically once touching barrier, not affect former tests ·Automatic eligible cuvettes detection & selection ·Select best test point by reaction curve, create new factor automatically ·High accurate optical system ·Support LIS interface
