■Microcomputer control, can be controlled by hand or by foot.

■The generator adopts LEEP which specializing in gynecological intrauterine event, increasing the accuracy, controllability, security of the surgery.

■Dealing with some kinds of pathological changes in obstetric and gynecology,   for example, cutting, electrocoagulation, cervical erosion, and some kinds of surgery that fit in peritoneoscope.

■Different electrodes have different effects in coagulation.

■An optional smoke evacuation system is available.

■Paticular illuminating ESU pencil can increase the clarity of wound healing.

Technical Specifications

Power: 220V±22V(110V±11V), 50Hz±1Hz

Operating frequency: 416kHz

Power rating:1100VA±10％

Five working modes:

◆Monopolar Cut

a) pure cut：1W～200W( Load 800Ω)

b) Blend1：1W～150W(Load 800Ω)

c) Blend2：1W～100W (Load 800Ω)

◆Monopolar Coag

d) Spray Coag：1W～80W( Load 800Ω)

e) Forced Coag：1W～120W( Load 800Ω)

◆Power Consumption :≦1100VA(Cutting function 200W)

Surgical Smoke Evacuation

blowing rate: 100 l/min @ 6mm tube

Noise: <60dB(A)

Start Control: Manus/Foot/Synchronize

Suction Adjust: 10%－100%

Stop delay time: 0－60s

AC Power: AC90~250V, 50Hz

Power consumption:< 350W

Filter Characteristics:99.999% @ 0.1-0.2μm

Active Carbon:97% @ 1 year
