■Highest power:200W

■Seven working modes: pure cut, blend1, blend2, blend3, spray coag, forced coag, bipolar coag.

■Microcomputer control, three-way power output, with different audible and visual indication during the process of outputting.

■2000(LEEP) generator adopts LEEP which specializing in gynecological intrauterine event, increasing the accuracy, controllability, security of the surgery.

■Dealing with some kinds of pathological changes in obstetric and gynecology,   for example, cutting, electrocoagulation, cervical erosion, and some kinds of surgery that fit in peritoneoscope.

■Different electrodes have different effects in coagulation.

■An optional smoke evacuation system is available.

■Particular illuminating ESU pencil can increase the clarity of wound healing.

Technical Specifications

Power: 220V±22V, 50Hz±1Hz(110V±11V,50/60Hz)

Operating frequency: 416KHz

Power rating: 1100VA±10％

Seven working modes:

Mono-polar Cut

a) pure cut：1W～200W( Load 800Ω)

b) Blend1：1W～150W(Load 800Ω)

c) Blend2：1W～100W (Load 800Ω)

d) Blend3：1W～80W(Load 800Ω)

Mono-polar Coag

e) Spray Coag：1W～120W( Load 800Ω)

f) Forced Coag)：1W～80W( Load 800Ω)

◆Bipolar

g) Bipolar coagulation: 1W～50W ( Load 100Ω)

◆Power Consumption : ≤880VA(Cutting function 200W)



Surgical Smoke Evacuation  Parameter

blowing rate: 100 l/min @ 6mm tube

Noise: <60dB(A)

Start Control: Manus/Foot/Synchronize

Suction Adjust: 10%－100%

Stop delay time: 0－60s

AC Power: AC90~250V, 50Hz

Power consumption: < 350W

Filter Characteristics: 99.999% @ 0.1-0.2μm

Active Carbon: 97% @ 1 year



Packing List

Illuminating ESU Pencil         5pcs

Electrosurgical Pad              10pcs

Electrosurgical pad cable   1pcs

Footswitch                             1set

Bipolar Forceps and cable  1set

Vaginaldilator                      1pcs

Electrodes                          10pcs
